Exterior Finish: Zinc-plated for corrosion resistance
Design: Equal tee for connecting pipes of the same diameter
Leak Proofing: Leaky when unpressed for installation safety
Description
The Geberit Mapress Carbon Steel Equal Tee is designed to connect three sections of piping, providing an equal diameter connection for smooth flow distribution in high-pressure systems. This fitting is ideal for use in heating, cooling, and industrial applications where secure and efficient branch connections are required. Its durable, zinc-plated construction offers long-lasting performance and corrosion resistance, making it suitable for both commercial and industrial installations.
Key Features
Pressing Indicator: Features a visible pressing indicator that helps installers confirm a secure connection has been made, ensuring the fitting is properly pressed and leak-proof.
Leak Detection: Leaks if unpressed, giving installers a safety feature by allowing for quick identification of any unpressed fittings before system pressurisation.
Zinc-Plated Exterior: The non-alloy steel body is zinc-plated to provide excellent corrosion resistance, ensuring durability in a variety of environments, including indoor and outdoor installations.
CIIR Seal Ring: The black CIIR (chlorinated isobutylene-isoprene rubber) seal ring ensures a long-lasting and reliable seal, even in high-pressure applications, preventing leaks and system failures.
Pressing Socket with Protection Plug: Comes with a transparent protection plug to prevent dirt, debris, and damage during transportation and storage, ensuring the fitting remains clean and ready for installation.
Equal Branch Design: All three outlets are of equal diameter, allowing for uniform flow distribution in multi-directional piping systems.
SKU
Art. no.
DN
d, ø (mm)
arc (degrees)
L (cm)
L1 (cm)
l (cm)
Z (cm)
Z1 (cm)
487049
21001
10
12
90
5.6
3.5
2.8
1.1
1.8
487050
21002
12
15
90
6.4
3.9
3.2
1.2
1.9
487051
21003
15
18
90
6.8
4.1
3.4
1.4
2.1
487052
21004
20
22
90
7.4
4.4
3.7
1.6
2.3
487053
21005
25
28
90
8.4
5
4.2
1.9
2.7
487054
21006
32
35
90
10
5.7
5
2.4
3.1
487055
21007
40
42
90
11.4
6.5
5.7
2.7
3.5
487056
21008
50
54
90
13.8
7.7
6.9
3.4
4.2
IMPORTANT: The technical data given on this website is for preliminary information purposes only and is published without guarantee. All line drawings are for illustrative purposes only and should not be regarded as wholly accurate in every detail. We reserve the right to withdraw or to alter the specification of any product without notice. For more information, please consult our Terms of Business.
