PCL XF-Euro Safety Coupling Female Thread
Useful Information
Technical Specifications
- Nominal Bore: 7.4mm
- Flow Rate at 6 bar supply: 1,750 l/min at 0.5 bar p.d.
- Maximum Working Pressure: 16 bar / 200 psi
- Temperature Range: -40°C to 100°C
- Material: Steel with a corrosion-resistant finish
- Application: High-demand environments that require superior flow rate
- Origin: Made in Sheffield, UK
Description
Engineered for enhanced safety, this coupling features a two-stage, self-venting release mechanism that eliminates the risk of hose whip. The simple sliding sleeve operation allows for controlled pressure release before disconnecting the adaptor, ensuring a safer working environment. Designed to meet ISO 1998:4414 and EN 983:1996 safety standards, it is ideal for high-demand industrial and workshop applications.
Key Features
- Two-stage self-venting release for controlled disconnection
- Sliding sleeve operation for ease of use
- Prevents hose whip, improving workshop safety
- Interchangable with CEJN 320, Legris 25/26, Norgren 234/238, Rectus 25/26 and Schrader InterCheck 35
-
Complies with ISO 1998:4414 & EN 983:1996 safety standards
| SKU | Article Number | Thread Size |
| 488761 | AS71CF | 1/4" |
| 488762 | AS71EF | 3/8" |
| 488763 | AS71JF | 1/2" |
If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.
