Reducing Run Tee 90
Useful Information
Key Features / Tech Specs & Dimensions:
- Material: malleable iron (black)
- Female BSPP threads
| Product Code | Diameter A (inch) | Diameter B (inch) | Diameter C (inch) | a (mm) | b (mm) | c (mm) | z1 (mm) | z2 (mm) | z3 (mm) | Pressure Rating (bar) |
| 362348 | ½ | ⅜ | ⅜ | 26 | 26 | 25 | 13 | 16 | 15 | 25 |
| 362349 | ¾ | ½ | ½ | 30 | 31 | 28 | 15 | 18 | 15 | 25 |
| 362353 | 1 | ¾ | ¾ | 35 | 36 | 33 | 18 | 21 | 18 | 25 |
| 362357 | 1¼ | 1 | ¾ | 40 | 42 | 36 | 21 | 25 | 21 | 25 |
| 362358 | 1¼ | 1 | 1 | 40 | 42 | 38 | 21 | 25 | 21 | 25 |
| 362361 | 1½ | 1 | 1 | 42 | 46 | 38 | 23 | 29 | 21 | 25 |
| 362364 | 1½ | 1¼ | 1 | 46 | 48 | 42 | 27 | 29 | 25 | 25 |
| 362365 | 1½ | 1¼ | 1¼ | 46 | 48 | 45 | 27 | 29 | 26 | 25 |
| 362371 | 2 | 1½ | 1½ | 38 | 48 | 38 | 14 | 35 | 19 | 25 |
| 362374 | 2½ | 2 | 2 | 67 | 72 | 62 | 40 | 48 | 38 | 25 |
