EN175301-803, DIN43650 Connectors
Useful Information
- Manufacturer: Kavlico
- Cable socket with central screw M3 x 35
- Cable gland: PG11
- Conforms to DIN EN 175 301-803-A Standard
- Pin dimensions: 6.3mm x 0.8mm, 4.8mm x 0.8mm
- Voltage rating from 24V to 250V
- Contact Resistance: <= 4 m0hm
- Polyamide housing
- Tin plated contacts
- Temperature range: -40°C to 90°C
| Product Code | Rated Voltage | Rated Current | Suitable Cables (mm) | Current | Info |
| 373996 | 24V | 2A (SEV1011:1.5A) AC/1A DC | 4.5 - 11 | AC/DC | Red LED No Protection, Translucent White |
| 373997 | 24V | 2A (SEV1011:1.5A) AC/1A DC | 4.5 - 11 | DC | Red LED with Diode Protection, Translucent White |
| 373998 | 48V | 8A | 4.5 - 11 | DC | Red LED with Diode Protection, Translucent White |
| 373999 | 120V | 8A | 4.5 - 11 | AC/DC | Bipolar Yellow LED No Protection, Translucent White |
| 374000 | 230V | 8A | 4.5 - 11 | AC/DC | Bipolar Yellow LED No Protection, Translucent White |
| 374001 | 250V | 16A | 6 - 9 | AC/DC | No LED, Black |
| 374002 | 250V | 16A | 6 - 9 | AC/DC | No LED, Grey |
| 374003 | 250V | 2A (SEV1011:1.5A) AC/1A DC | 4.5 - 11 | AC/DC | Bridge-type Rectifier No LED, Black |
Useful Info:
This selection of electrical connectors are ideally suited for use with the Hermetically sealed pressure sensors.
If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.
