PVC Heavy Duty Hose
Useful Information
Key Features / Tech Specs & Dimensions:
- Material: polyvinyl chloride
- 3:1 safety factor at 20°C
- Operating temperature range: -5°C to 65°C
- Colour: grey
- Available in 10m and 30m coils
| Product Code | ID (inch) | ID (mm) | OD (mm) | Length (m) | Operating Pressure (bar) | Bursting Pressure (bar) | Bend Radius (mm) | Weight (kg) |
| 375673 | 2 | 50 | 60 | 10 | 7 | 24 | 300 | 10 |
| 375674 | 3 | 76.1 | 87.9 | 10 | 5 | 20 | 450 | 16.8 |
| 375675 | 4 | 103.9 | 120.2 | 10 | 5 | 16 | 630 | 26.6 |
| 375676 | 6 | 155.8 | 175.8 | 10 | 4 | 12 | 1100 | 52 |
| 375677 | 2 | 50 | 60 | 30 | 7 | 24 | 300 | 30 |
| 375678 | 3 | 76.1 | 87.9 | 30 | 5 | 20 | 450 | 50.4 |
| 375679 | 4 | 103.9 | 120.2 | 30 | 5 | 16 | 630 | 80 |
| 375680 | 6 | 155.8 | 175.8 | 30 | 4 | 12 | 1100 | 156 |
Â
Please note: The pressure ratings given are based on the short term burst pressure of the hose at 20°C based on a 3:1 safety factor. If the temperature is increased then the pressure rating will be reduced.
IMPORTANT: The technical data given on this website is for preliminary information purposes only and is published without guarantee. All line drawings are for illustrative purposes only and should not be regarded as wholly accurate in every detail. We reserve the right to withdraw or to alter the specification of any product without notice. For more information, please consult our Terms of Business.
Useful Info:
Manufactured in flexible grey PVC with a white spiral helix, this hose has been designed for the conveyance of water and chemicals, as well as powder, sand, gravel, cement, iron filings and more.
This hose is ideally suited for heavy duty pumping and suction applications, particularly within the construction, agricultural, shipping, and civil engineering sectors.
The high abrasion resistance of this hose makes it ideal for transporting coarse, grainy materials.
Our heavy duty PVC suction and delivery hose offers resistance to most oxidising and reducing agents, diluted acids and diluted alkalis.
If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.
