Georg Fischer PROGEF BF Union End
Useful Information
PROGEF Standard PP, from Georg Fischer, is manufactured from a polypropylene homopolymer and has been shown to offer excellent resistance against stress fracture, impact, abrasion and chemicals and is therefore suited for use in industrial applications where chemical production and distribution is required.
These PROGEF union ends are infrared welding compatible butt fusion ends for conventional butt-welding according to DVS 2207 part 11.
| Material | PP-H |
| Temperature Range | 0°C to 80°C |
| Pressure Rating | 10 Bar |
| Size Range | 20mm - 63mm |
| Product Code | d (mm) | L (mm) | L1 (mm) | D (mm) | e (mm) | Weight (kg) |
| 398055 | 20 | 54 | 38 | 30 | 1.9 | 0.009 |
| 398056 | 25 | 57 | 42 | 39 | 2.3 | 0.017 |
| 398057 | 32 | 60 | 41 | 45 | 2.9 | 0.026 |
| 398058 | 40 | 63 | 42 | 57 | 3.7 | 0.043 |
| 398059 | 50 | 66 | 44 | 63 | 4.6 | 0.058 |
| 398060 | 63 | 69 | 45 | 78 | 5.8 | 0.095 |
Â
If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.
