Operating Temperature: 0-100°C (For cold and hot potable water)
Maximum Operating Pressure: 16 bar/ 1600kPa (For cold and hot potable water)
Seal Ring: CIIR black seal ring (up to 54 mm), EPDM black seal ring (over 54 mm)
Connection Technology: Press-fit with pressing indicator and leak detection
Installation: Suitable for both surface-mounted and concealed installations
Description
The Geberit Mapress Copper Reducing Tee is designed to create a secure and efficient connection between copper pipes of varying diameters. This fitting is ideal for potable water installations, as well as heating and cooling circuits in both residential and industrial settings. Its reducing design allows for the joining of different pipe sizes, while the press-fit technology ensures a reliable and quick installation without the need for hot works.
Key Features
High-Quality Copper Material: Made from Cu-DHP copper CW024A (EN 1412), the pipe bridge offers excellent durability and corrosion resistance, ensuring reliable long-term performance in demanding systems such as potable water, heating, and cooling circuits.
Press-Fit Technology: The press-fit connection eliminates the need for welding or soldering, reducing installation time and eliminating fire hazards, making it particularly suitable for residential settings and confined spaces.
Leak Detection: The pipe bridge is designed to be leaky if unpressed, allowing installers to easily identify any unpressed connections, ensuring that the system is fully secure before use.
Hygienic Installation: The seal rings are protected from dirt during the installation process, ensuring a clean and hygienic connection, which is especially important in potable water systems.
Clear Identification: Colour-coded indicators and transparent protection plugs allow for easy identification of the pipe bridge’s materials and application ranges, helping to prevent confusion with third-party products.
Versatile Application: Suitable for both surface-mounted and concealed installations, the Geberit Mapress Copper Pipe Bridge can be used in a wide range of plumbing and heating systems, offering flexibility in different project types.
SKU
Art. no.
DN
d, ø (mm)
arc (degrees)
L (cm)
L1 (cm)
L2 (cm)
486836
60802
12
15
30
6
16.5
3.2
486837
60803
15
18
30
6
16.6
3.3
486838
60804
20
22
30
6
16.8
3.5
Application Purposes
Operating Temperature
Maximum Operating Pressure
Liquid Media
For cold and hot potable water
0–100 °C
16 bar / 1600 kPa (5)
For cooling and heating water without antifreeze agent
0–100 °C
16 bar / 1600 kPa (4)
For cooling and heating water with antifreeze agent
-30 – +120 °C
16 bar / 1600 kPa (4)
For district heating water ≤ 120 °C
0–120 °C
16 bar / 1600 kPa (4) (9)
For service water and process water
0–120 °C
16 bar / 1600 kPa (7)
Gaseous Media
For compressed air (purity class oil 2-3) (1)
0–100 °C
12 bar / 1200 kPa (6)
For compressed air (purity class oil 0-X) (1)
0–100 °C
12 bar / 1200 kPa (6)
For negative pressure (2)
0–100 °C
Abs. ≥ 0,2 bar/20 kPa
For inert gases (e.g. nitrogen)
0–100 °C
12 bar / 1200 kPa6)
For natural gases
-20 – +70 °C
MOP 5 / GT 1
For liquefied gases
-20 – +70 °C
MOP 5 / GT 1
(1) Usable negative pressure for Geberit piping systems: The usable negative pressure results from the air pressure at the installation site minus the absolute pressure of 200 mbar. Example: 980 mbar air pressure - 200 mbar absolute pressure = 780 mbar usable negative pressure in the piping system
(2) Usable negative pressure for Geberit piping systems: The usable negative pressure is calculated on the basis of the air pressure at the place of installation minus the absolute pressure of 200 mbar. Example: 980 mbar air pressure - 200 mbar absolute pressure = 780 mbar usable negative pressure in the piping system
(3) Lifetime with collector standstill: 200 h/a at 180 °C; 60 h/a at 200 °C; total 500 h/lifetime at 220 °C
(4) Use of inhibitors, corrosion-protection agents, antifreeze agents only after approval by Geberit
(5) 10 bar / 1000 kPa for MasterFix and MeplaFix
(6) Approved up to d54 mm
(7) Following Geberit approval
(8) Oil purity class in accordance with ISO 8573-1:2010E; for details on moisture and particles, see technical information "Geberit Piping Systems for Compressed Air Installations"
(9) Not for fittings with EPDM, black seal rings
