FloPlast White Unicom Compression Waste

The Floplast White Unicom Compression Waste System is a versatile and easy-to-install solution for waste drainage applications. Manufactured from polypropylene (PP), it features a secure compression fitting design that accommodates both plastic and copper pipes. This system provides a reliable and leak-proof connection without the need for solvent welding.

Designed to BS EN 1451-1 and BS EN 681 standards, the Unicom Compression Waste System offers excellent durability, chemical resistance, and flexibility. It is available in 32mm, 40mm, and 50mm sizes, making it a suitable choice for various domestic and commercial applications.

The Floplast White Unicom Compression Waste System is suitable for:

• Domestic and commercial waste plumbing – Ideal for kitchens, bathrooms, and utility rooms.
• Use with multiple pipe types – Compatible with both plastic (ABS, PVC, PP) and copper pipes.
• New builds and refurbishment projects – It provides flexibility for both initial installation and retrofit applications.

•  Quick and simple installation – Compression fittings allow for tool-free assembly, reducing installation time.
•  Secure, leak-proof connection – No solvent welding is required, making it a cleaner and safer alternative.
•  Reversible and reusable fittings – Can be easily dismantled and repositioned, allowing for modifications and maintenance.
•  Durable polypropylene construction – Lightweight yet impact-resistant for long-term reliability.
•  Complies with British Standards – BS EN 1451-1 (plastic waste piping systems) and BS EN 681 (elastomeric sealing materials).

• Material: Polypropylene (PP)
• Available Sizes: 32mm, 40mm, 50mm
• Jointing Method: Compression fitting (no solvent welding required)
• Compatible Pipe Materials: Plastic (ABS, PVC, PP) and Copper
• Colour: White

Preparation:

• Ensure the pipe ends are clean, dry, and free from debris.
• Cut the pipe squarely to the required length using a fine-toothed saw and remove burrs.

Assembly:

• Slide the compression nut onto the pipe, followed by the sealing washer.
• Insert the pipe into the fitting, ensuring a firm and secure connection.
• Hand-tighten the compression nut to seal the joint.
• For a more secure connection, use SL40 Spray, SG100 Tub, or SG800 Gel for lubrication.

Adjustments & Modifications:

• If repositioning is needed, simply loosen the compression nut, adjust the fitting, and retighten.

Support & Fixing Recommendations (BS EN 12056-2):

• Vertical installations: Secure at 1.2m intervals.
• Horizontal installations: Secure at 0.5m intervals for 32mm & 40mm, and 0.6m for 50mm.
• Conduct a water leak test before commissioning the system.
• Check all compression joints to ensure they are properly tightened and sealed.
