ABS Inch Tee 90° Plain

Skip to the beginning of the images gallery

Useful Information

Effast plain ABS tee 90° fittings are available in sizes 1/2" to 8".

This fitting is used to join three lengths of ABS pipe, of the same diameters.

Manufacturer	Effast
Material	ABS - acrylonitrile butadiene styrene
Pressure Rating	16 bar at 20°C
Operating Temperature	-40°C to +60°C

ABS Tee 90 Plain Diagram

Product Code	Nominal Size (inch)	L (mm)	Z (mm)	E (mm)
353262	1/2	17	11	27
353263	3/4	20	14	33
353264	1	23	17	41
353265	1 1/4	27	21	52
353266	1 1/2	32	26	61
353267	2	37	33	75
353268	2 1/2	44	39	90
353269	3	52	45	107
353270	4	63	62	133
353271	5	76	71	164
353272	6	93	86	198
353273	8	116	116	258

IMPORTANT: The technical data given on this website is for preliminary information purposes only and is published without guarantee. All line drawings are for illustrative purposes only and should not be regarded as wholly accurate in every detail. We reserve the right to withdraw or to alter the specification of any product without notice. For more information, please consult our Terms of Business.

If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.

All text and product images are the intellectual property and copyright of Pipestock Limited

More Info

Grouped product items
Code	Product Name	List Price	You Save	You Pay
353262	ABS Tee 90 Plain 1/2"	£7.08	80%	£1.42
353263	ABS Tee 90 Plain 3/4"	£7.18	80%	£1.44
353264	ABS Tee 90 Plain 1"	£10.07	80%	£2.01
353265	ABS Tee 90 Plain 1 1/4"	£14.28	80%	£2.86
353266	ABS Tee 90 Plain 1 1/2"	£20.88	80%	£4.18
353267	ABS Tee 90 Plain 2"	£31.94	80%	£6.39
353268	ABS Tee 90 Plain 2 1/2"	£55.17	80%	£11.03
353269	ABS Tee 90 Plain 3"	£93.13	80%	£18.63
353270	ABS Tee 90 Plain 4"	£136.75	80%	£27.35
353271	ABS Tee 90 Plain 5"	£362.75	80%	£72.55
353272	ABS Tee 90 Plain 6"	£477.86	80%	£95.57
353273	ABS Tee 90 Plain 8"	£979.59	80%	£195.92
