ABS Inch Adaptor Plain M x Thread F

Loading...
Useful Information

Effast ABS adaptor fittings, with plain spigot x female BSP thread ends, are available in sizes 1/2" to 2".

Used to join together an ABS pipe to a fitting with a male thread.

ABS solvent cement should be used, along with cleaner, to glue the plain end and the pipe together.



Manufacturer Effast
Material ABS - acrylonitrile butadiene styrene
Pressure Rating 16 bar at 20°C
Operating Temperature -40°C to +60°C



ABS Adaptor Plain M x Thread F Diagram

Product Code Nominal Size (inch) L1 (mm) L2 (mm) Z (mm) E (mm)
352965 1/2 17 15 24 28
352966 3/4 20 16 27 34
352967 1 23 19 30 42
352968 1 1/4 27 21 36 51
352969 1 1/2 32 21 41 58
352970 2 39 25 48 72



IMPORTANT: The technical data given on this website is for preliminary information purposes only and is published without guarantee. All line drawings are for illustrative purposes only and should not be regarded as wholly accurate in every detail. We reserve the right to withdraw or to alter the specification of any product without notice. For more information, please consult our Terms of Business.



If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.



All text and product images are the intellectual property and copyright of Pipestock Limited

Grouped product items
CodeProduct NameList PriceYou SaveYou Pay Quantity
352965ABS Adaptor Male Spigot Plain x Threaded Female 1/2" £7.92 76%
£1.90
352966ABS Adaptor Male Spigot Plain x Threaded Female 3/4" £9.58 76%
£2.30
352967ABS Adaptor Male Spigot Plain x Threaded Female 1" £13.31 76%
£3.19
352968ABS Adaptor Male Spigot Plain x Threaded Female 1 1/4" £16.88 76%
£4.05
352969ABS Adaptor Male Spigot Plain x Threaded Female 1 1/2" £22.96 76%
£5.51
352970ABS Adaptor Male Spigot Plain x Threaded Female 2" £32.05 76%
£7.69
